GIO-FLOCK
Roll Size: 20”
To see a larger color display. Open the following link to our manufacturer: [click here]
Call for Pricing.
Instructions
- Design artwork and mirror the image before cutting.
- Cut the material using a CAD cutter/plotter with the flock side facing up.
- Weed the excess film surrounding the graphic carefully.
- Pre-heat the fabric for 2–3 seconds to remove moisture and wrinkles.
- Position the design on the garment with the carrier sheet facing up.
- Heat press with medium pressure (approximately 50–60 psi).
- Heat press for 8–10 seconds at 150°C (302°F).
- Peel the carrier warm.
- If needed, re-press for 2–3 seconds using a teflon sheet for better adhesion.
Characteristics
- Soft, velvety / suede-like surface that provides a premium tactile feel.
- Raised (3D) texture that adds depth and dimension to designs.
- Made with high-density flock fibers for a rich and textured finish.
- Matte, non-shiny appearance for a clean and professional look.
- Thicker than standard HTV, giving a bold and durable feel.
- Excellent cutting and weeding performance for efficient production.
- Compatible with CAD cutters/plotters for precise design cutting.
- Strong adhesion when heat applied correctly.
- Wash durable and resistant to peeling and fading.
- Suitable for cotton, polyester, and blended fabrics.
- Ideal for logos, lettering, numbers, and sportswear applications.
- Provides an embroidery-like effect without stitching.
- Can be layered with other HTV materials for enhanced designs.
Material Specifications
- Material Type: Flock Heat Transfer Vinyl (HTV)
- Composition: Viscose Rayon fibers (flock layer)
- Carrier: Transparent PET carrier film
- Adhesive: Heat-activated hot-melt adhesive
- Thickness: Approx. 460 microns (±10 µm)
- Finish: Velvet / suede-like textured surface
- Backing: Pressure-sensitive carrier for easy positioning
- Temperature Resistance: Suitable for heat press up to 150°C (302°F)
- Wash Resistance: Up to 60°C (140°F)
- Available Widths: 510 mm / 1020 mm
- Color Range: Multiple standard colors available
More Information
Additional information
It’s time to shine! GIO-FLOCK is a printable and cuttable HTV film unlike any other that will put a sparkle back into your customers’ eyes!
